• Analysis of complex, multiple-pulse waveforms
• Standardized industrial HF measurement
• HF leakage current measurement
• REM/ARM/CQM test adjustable in 1 O steps
• Ultra-fast digitizing of HF waveforms
• Sampling of up to 16 million data points
• Internal precision loads adjustable from 1 to 6400 O in 1 O steps
• Integrated real-time operating system with ¼ VGA color touch-screen
• Automated, freely definable test sequences
• Automated current-power curves with various power levels per load value setting
• Compatible with external test loads
• Definable screen display
• USB, RS 232 and Ethernet communication ports
• Dedicated connectors for external keyboard and mouse
• Automatic or manual activation of the ESU generator during the load curve test
• Remote control of the ESU generator is possible
• Generation of test reports

1 Operating Instruction

1 Cable set
