Compact Controller, 96 x 96 mm with Dig. Displ. for Actual Value and Heating Curr.

  • Harmonic-free PDPI control algorithm
  • Self-optimization for ideal control parameters
  • Digital displays for actual value and setpoint (manipulating factor, heating current)
  • Setpoint can be keyed in
  • Control outputs can be shut down with a single keystroke
  • Programmable limit values and setpoint limiting
  • Sensor error display
  • Heating current acquired with an external transformer
  • IP 65 protection at front panel
  • Extremely small installation depth of only 50 mm
  • 3 Years Warranty
  • Made in Germany

Order options:

  • Controller as two-position controller, two-position controller with limit contact, or three-position controller, without feedback loop with 1 or 2 limit contacts
  • Medium (~ 50 s) or short time response (~ 25 s)
  • Type L, J, K, R and S thermocouple, and PT100 (2-wire) measuring ranges
  • 1st switching output: relay or transistor
  • Auxiliary voltages: 110/220 VAC , 110/240 VAC

Istruzioni per l’uso
Certificato CE
Scheda tecnica

  • Controller
  • 2 mounting components
  • Bilingual operating instructions German/English
