MAVOWATT 210 Rogowski 1500/40

MAVOWATT 210 Rogowski 1500/40 Flexible AC Sensor

The MAVOWATT 210 Rogowski flexible AC sensor enables safe, accurate and flexible measurements at conductors of any type in conjunction with the MAVOWATT 210.

  • Flexible probe for highly accurate measurement of alternating current via connection to the MAVOWATT 210
  • Wide range of applications in all types of three-phase systems
  • Ideal for applications with limited space and locations which are difficult to access with rigidly mounted current probes
  • Easy to use in tight spaces thanks to small probe cross-section of just 15.5 mm
  • The large frequency range is also well suited for measuring harmonics and power quality.
  • Accurate measurements even with extremely low amperage thanks to the probe’s broad dynamic range and high response sensitivity
  • Highly accurate and reliable measurements for demanding applications
  • High levels of safety for the user thanks to measurement category 1000 V @ CAT III and 600 V @ CAT IV
  • Unlimited overload capacity and designed for continuous operation

  • Measuring range from 150 to 1500 A within a frequency range of 45 to 65 Hz
  • Large bandwidth of 10 Hz to 20 kHz for harmonic analysis
  • Minimal influence due to conductor position or disturbance fields
  • Current sensor with IP 61 protection
  • High levels of safety for the operator, measuring category 1000 V @ CAT III, 600 V @ CAT IV and unlimited overload capacity, designed for continuous operation
  • 40 cm coil length with a diameter of 10.6 cm
  • Connector cable length: 2 m
  • Accuracy: 0.5% per IEEE C57.13, class 0.6
  • Only compatible with MAVOWATT 210

The MAVOWATT 210 Rogowski is an alternating current probe based on the Rogowski principle. It can be used to measure alternating currents by connecting it to the MAVOWATT 210. The flexible probes also permit current measurement at difficult-to-access locations. The flexible current transducers are capable of enclosing one or more conductors of various types (insulated cables, busbars, pipes).

MAVOWATT 210 Rogowski current probes are designed for alternating current measurements in all types of 3-phase systems. They’re supplied with power directly from the measuring instrument. No external power supply is required.

Istruzioni per l’uso
Certificato CE
Scheda tecnica

1x MAVOWATT 210 Rogowski 1500/40 flexible AC sensor
1x operating instructions
