LABKON P500 35/14

Lab Power Supplies, Computer Controlled

  • Power: 500 W
  • voltage: up to 120 V, current: up to 14,5 A
  • CV and CC operating modes, automatic switching
  • Output voltage and output current can be continuously regulated from 0 up to nominal value
  • Several groups of parameters (device settings) can be saved and retrieved.
  • Floating power output / no grounding
  • Highly efficient Safe electrical separation
  • Output can be switched on and off Supports SCPI (standard commands for programmable instruments)
  • Settings selected by means of rotary encoder and keypad Multifunctional
  • LCD panel Protective devices – amongst others overvoltage protection
  • Auto-sensing mode
  • Benchtop instrument, also suitable for mounting to a 19″ rack
  • Rugged and compact with simple handling
  • RS 232 port, optional GPIB and USB
  • Calibration (adjustment) function

  • Type LABKON P500
  • Power (W) 500
  • Voltage (V) 0-35
  • Current (A) 0-14.5
  • Article No. K148A

Istruzioni per l’uso
Certificato CE
Scheda tecnica
Opuscolo, volantino, brochure, …

1 Benchtop device
1 Protective rubber housing
1 Mains power cable (earthing contact)
1 Safety instructions
1 CD-ROM with operating instructions in German and English
